Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction machines. Equipment such as boom lifts, aerial lifts and manlifts. These machinery are designed to facilitate access to difficult to reach areas, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves just in one direction and includes platforms, or steps or handholds that are attached to the unit in order to transport workers from every floor.
TB85
Terex's TB85 man lift offers a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions that measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is around 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
